CE certificate machine to rubber mat / vulcanized rubber floor mat machine
Welcome to QINGDAO XIANGJIE RUBBER MACHINERY CO.,LTD ( with 21 years experience and all machine have passed CE&ISO9001:2008 certificate)
Main technical parameter of rubber mat vulcanizing machine:
Parameter/ Specification | XLE-Q1250x2050 | XLE-Q1000x1400 |
clamp capacity(MN) | 10.00 | 4.800 |
Hot plate specification(mm) | 1250x2050 | 1000x1400 |
Space between(mm) | 450 | 400 |
plunger diameter | 650 | 450 |
Maximum working hydraulic pressure(Mpa) | 15 | 15 |
Compressed air pressure(Mpa) | 0.6-0.8 | 0.6-0.8 |
Maximum steam pressure(Mpa) | 1.0 | 1.0 |
Electric machine power(kw) | 15 | 15 |
Overall dimension(mm) | 1300x800x1500 | 2500x1400x3330 |
Weight(kg) | 45000 | 23000 |
Feature
1. Automatic ascending,bumping,pressurization and descending operations.
2. High speed ascending, pressure retaining for better product quality.
3. Fast release valve for fast descending but incorporates adjustable speed.
4. Depressurization can be adjusted to suit thickness of products.
5. Special designed platens for even heating area.
6. The above features can be incorporated in automatic and semi-automatic machines.
